Fast Pass Turnstile Swing Barrier Gate
Model No- TP-3503
All the gates models are space efficient security barriers, with a compact design, yet offer sufficient space to integrate any access control system. They can be mounted with display, passage counter, card reader, token operation traffic lights, command console, alarm system against unauthorised entries, interfaced with a PC through a RS232(RS485,TCP-IP)line. The unique swing arm feature provides a fail-safe safety solution in case of an emergency or power failure,providing egress in case of crisis evacuations. Durability with minimal maintenance means years and millions of trouble free passages. The gate creates a secure environment in. for example, a reception area. Our gates are used in applications including stadiums and arenas, perimeter and interior security, recreation and amusement parks, retail crowd control, transit fare collection and lobby access control
Model Number: | TP-3503 |
Product Size: | 1400*185*1020mm |
Pass Width: | 600-900mm |
Net Weight: | 65kg |
Thickness: | 1.2mm |
Material: | 1.2mm SUS 304 Hailine 400# |
Top cover Material: | Acrylic+1.5mm SUS304 |
Filling Panel Material: | 10mm Transparent Acrylic |
Arm Material: | 10mm Transparent Acrylic |
Driver: | Brushed Motor |
Infrared Sensor: | 5pairs |
Pass rate: | 35-40p/m |
Power Supply: | 100-240V(AC) |
Operational Voltage: | 24V(DC) |
Max Power Consumption: | 35w |
Frequency: | 50-60hz |
Working Temperature: | -25 to +70 ℃ |
MCBF: | 5,000,000cycles |
Our advantage:
- 90% of production processes are developed by ourselves so we can control the costs and provide the competitive price correspondingly.
- We use Stainless steel, the best brand in China.
- Our power supply is the from best brand
- We take 3M glue imported from American instead of the glass glue which other counterparts use.
Germany “Optibelt” and American “Gates” is the belt we are using now.
Function–
- Swing Turnstile Gate is designed to control pedestrians entering or exiting restricted areas, usually used of high pedestrian traffic flow in both directions.
- The body is made of brushed stainless steel and black rubber.
- Swing Turnstile is ideal for both indoor and outdoor settings.
- Swing Barrier has standard relay signal, which can be integrated with any kind of third-party access control system (e.g.: RFID, Fingerprint and Biometric reader device).
- Swing Gate has sufficient space, which can mount with any type of external device.( e.g.: Display, Counter, Reader, Push button, Card collector, Coin insert,Barcode/QRreader).
- In case of emergency, the optical turnstile arms will open automatically to allow free passage.
- Swing Door support standard and handicapped type with wide passageway, wheelchair, pedestrian with large luggage can pass.
- Swing Barrier Gate is suitable for areas with general pedestrian traffic.(e.g.: Hotel, Building, Dormitory, Station, Supermarket)
